Paradigm CI Home H55-LCR v2
CA$399.99 each
Request a quote
Or call (613) 830-6787
The add to cart button will appear once you select the values above
The Paradigm CI Home H55-LCR v2 is an in-wall speaker from Paradigm's CI Home line.
Paradigm describes its design as: 3-driver, 2-way in-wall left/center/right, ABS chassis & mounting clamps.
Paradigm specifies an on-axis frequency response of ±2 dB from 75 Hz - 20 kHz and low-frequency extension to 60 Hz.
Available finishes: White, paintable grille, black speaker.
Call (613) 830-6787 or request a quote.
| Specifications | |
|---|---|
| Sold as | each |
| Design | 3-driver, 2-way in-wall left/center/right, ABS chassis & mounting clamps |
| Crossover | 2nd-order electro- acoustic at 2.5 kHz |
| Frequency response (on-axis) | ±2 dB from 75 Hz - 20 kHz |
| Frequency response (30° off-axis) | ±2 dB from 75 Hz - 15 kHz |
| High frequency driver | 3/4” (1.9cm) Exclusive Perforated Phase-Aligning (PPA™) Tweeter Lens |
| Mid/bass frequency driver | Two 5.5” (13.9cm) Mineral-filled Polypropylene Cone |
| Sensitivity room / anechoic | 89 dB / 85 dB |
| Low frequency extension | 60 Hz |
| Suitable amplifier power range | 15-100 W |
| Maximum input power | 70 W |
| Impedance | Compatible with 8 ohms |
| Accessories (not included) | PB-8X12N |
| Cut-out dimensions | 8-1/4” x 11-5/8” (20.9cm x 29.5cm) |
| Minimum mounting depth | 2-3/4” (7cm) |
| Dimensions (H × W × D) incl. grille | 12-5/8” x 9-1/4” x 3-1/2” (32.1cm x 23.5cm x 8.8cm) |
| Weight | 5.9 lbs (2.7 kg) |
| Finishes | White, paintable grille, black speaker |
